第三章 ConfigController源代码解析

type ConfigStore interface {
	Schemas() collection.Schemas

	Get(typ resource.GroupVersionKind, name, namespace string) *Config
	List(typ resource.GroupVersionKind, namespace string) ([]Config, error)
	Create(config Config) (revision string, err error)
	Update(config Config) (newRevision string, err error)
	Delete(typ resource.GroupVersionKind, name, namespace string) error
    ...
}

type ConfigStoreCache interface {
	ConfigStore

	RegisterEventHandler(kind resource.GroupVersionKind, handler func(Config, Config, Event))
	Run(stop <-chan struct{})
	HasSynced() bool
}

type IstioConfigStore interface {
	ConfigStore
	ServiceEntries() []Config
	Gateways(workloadLabels labels.Collection) []Config
    ...
}

type store struct {
	schemas collection.Schemas
	stores map[resource.GroupVersionKind][]model.ConfigStore
    ...
}

// List all configs in the stores.
func (cr *store) List(typ resource.GroupVersionKind, namespace string) ([]model.Config, error) {
    ...
	configMap := make(map[string]struct{})

	for _, store := range cr.stores[typ] {
		storeConfigs, err := store.List(typ, namespace)
        ...
		for _, config := range storeConfigs {
			key := config.Type + config.Namespace + config.Name
			if _, exist := configMap[key]; exist {
				continue
			}
			configs = append(configs, config)
			configMap[key] = struct{}{}
		}
	}
	return configs, errs.ErrorOrNil()
}

type storeCache struct {
	model.ConfigStore
	caches []model.ConfigStoreCache
}

func (cr *storeCache) RegisterEventHandler(kind resource.GroupVersionKind, handler func(model.Config, model.Config, model.Event)) {
	for _, cache := range cr.caches {
		if _, exists := cache.Schemas().FindByGroupVersionKind(kind); exists {
			cache.RegisterEventHandler(kind, handler)
		}
	}
}

type Server struct {
    ...
	environment *model.Environment

	configController  model.ConfigStoreCache

	ConfigStores      []model.ConfigStoreCache
    ...
}

type Environment struct {
	IstioConfigStore
    ...
}

var (
    ...
	discoveryCmd = &cobra.Command{
		Use:   "discovery",
		Short: "Start Istio proxy discovery service.",
		Args:  cobra.ExactArgs(0),
		RunE: func(c *cobra.Command, args []string) error {
			discoveryServer, err := bootstrap.NewServer(serverArgs)
            ...
			if err := discoveryServer.Start(stop); err != nil {
				return fmt.Errorf("failed to start discovery service: %v", err)
			}
            ...
		},
	}
)


func init() {
    ...
	rootCmd.AddCommand(discoveryCmd)
    ...
}

func main() {
	if err := rootCmd.Execute(); err != nil {
		log.Errora(err)
		os.Exit(-1)
	}
}

func NewServer(args *PilotArgs) (*Server, error) {
    ...
	s := &Server{
        ...
		environment:     e,
        ...
	}

    ...
	if err := s.initControllers(args); err != nil {
		return nil, err
	}
}

func (s *Server) initControllers(args *PilotArgs) error {
    ...
	if err := s.initConfigController(args); err != nil {
		return fmt.Errorf("error initializing config controller: %v", err)
	}
	return nil
}

func (s *Server) initConfigController(args *PilotArgs) error {
	meshConfig := s.environment.Mesh()
	if len(meshConfig.ConfigSources) > 0 {
		if err := s.initMCPConfigController(args); err != nil {
			return err
		}
	} else if args.Config.FileDir != "" {
		store := memory.Make(collections.Pilot)
		configController := memory.NewController(store)
		s.ConfigStores = append(s.ConfigStores, configController)
	} else {
		configController, err := s.makeKubeConfigController(args)
        ...
		s.ConfigStores = append(s.ConfigStores, configController)
        ...
	}
    ...

	if hasKubeRegistry(args.Service.Registries) && meshConfig.IngressControllerMode != meshconfig.MeshConfig_OFF {
		s.ConfigStores = append(s.ConfigStores,
			ingress.NewController(s.kubeClient, meshConfig, args.Config.ControllerOptions))
        ...
	}

	aggregateConfigController, err := configaggregate.MakeCache(s.ConfigStores)
	if err != nil {
		return err
	}
	s.configController = aggregateConfigController

	// Create the config store.
	s.environment.IstioConfigStore = model.MakeIstioStore(s.configController)

	// Defer starting the controller until after the service is created.
	s.addStartFunc(func(stop <-chan struct{}) error {
		go s.configController.Run(stop)
		return nil
	})

	return nil
}

func NewServer(args *PilotArgs) (*Server, error) {
	e := &model.Environment{
		ServiceDiscovery: aggregate.NewController(),
		PushContext:      model.NewPushContext(),
		DomainSuffix:     args.Config.ControllerOptions.DomainSuffix,
	}

	s := &Server{
		clusterID:       getClusterID(args),
		environment:     e,
        ...
	}

    ...

	if err := s.initControllers(args); err != nil {
		return nil, err
	}

    ...
	if err := s.initRegistryEventHandlers(); err != nil {
		return nil, fmt.Errorf("error initializing handlers: %v", err)
	}
    ...

	return s, nil
}

// initRegistryEventHandlers sets up event handlers for config and service updates
func (s *Server) initRegistryEventHandlers() error {
    ...

	if s.configController != nil {
		configHandler := func(_, curr model.Config, event model.Event) {
			pushReq := &model.PushRequest{
				Full: true,
				ConfigsUpdated: map[model.ConfigKey]struct{}{{
					Kind:      curr.GroupVersionKind(),
					Name:      curr.Name,
					Namespace: curr.Namespace,
				}: {}},
				Reason: []model.TriggerReason{model.ConfigUpdate},
			}
			s.EnvoyXdsServer.ConfigUpdate(pushReq)
            ...
		}
		schemas := collections.Pilot.All()
        ...
		for _, schema := range schemas {
            ...
			s.configController.RegisterEventHandler(schema.Resource().GroupVersionKind(), configHandler)
		}
	}

	return nil
}

func (cr *storeCache) RegisterEventHandler(kind resource.GroupVersionKind, handler func(model.Config, model.Config, model.Event)) {
	for _, cache := range cr.caches {
		if _, exists := cache.Schemas().FindByGroupVersionKind(kind); exists {
			cache.RegisterEventHandler(kind, handler)
		}
	}
}
