第二章 ServiceController源代码解析

type ServiceInstance struct {
	Service     *Service       `json:"service,omitempty"`
	ServicePort *Port          `json:"servicePort,omitempty"`
	Endpoint    *IstioEndpoint `json:"endpoint,omitempty"`
}

type Instance interface {
	model.Controller
	model.ServiceDiscovery

	// Provider backing this service registry (i.e. Kubernetes, Consul, etc.)
	Provider() ProviderID

	// Cluster for which the service registry applies. Only needed for multicluster systems.
	Cluster() string
}

// ProviderID defines underlying platform supporting service registry
type ProviderID string

const (
	// Mock is a service registry that contains 2 hard-coded test services
	Mock ProviderID = "Mock"
	// Kubernetes is a service registry backed by k8s API server
	Kubernetes ProviderID = "Kubernetes"
	// Consul is a service registry backed by Consul
	Consul ProviderID = "Consul"
	// MCP is a service registry backed by MCP ServiceEntries
	MCP ProviderID = "MCP"
	// External is a service registry for externally provided ServiceEntries
	External = "External"
)

type Controller struct {
	registries []serviceregistry.Instance
	storeLock  sync.RWMutex
}

func (c *Controller) Services() ([]*model.Service, error) {
    ...
	services := make([]*model.Service, 0)

	for _, r := range c.GetRegistries() {
		svcs, err := r.Services()
        ...
			services = append(services, svcs...)
        ...
		}
	}
	return services, errs
}

type Server struct {
    ...
	environment *model.Environment
	kubeRegistry *kubecontroller.Controller
	serviceEntryStore *serviceentry.ServiceEntryStore
    ...
}

type Environment struct {
	ServiceDiscovery
    ...
}

var (
    ...
	discoveryCmd = &cobra.Command{
		Use:   "discovery",
		Short: "Start Istio proxy discovery service.",
		Args:  cobra.ExactArgs(0),
		RunE: func(c *cobra.Command, args []string) error {
			discoveryServer, err := bootstrap.NewServer(serverArgs)
            ...
			if err := discoveryServer.Start(stop); err != nil {
				return fmt.Errorf("failed to start discovery service: %v", err)
			}
            ...
		},
	}
)


func init() {
    ...
	rootCmd.AddCommand(discoveryCmd)
    ...
}

func main() {
	if err := rootCmd.Execute(); err != nil {
		log.Errora(err)
		os.Exit(-1)
	}
}

func NewServer(args *PilotArgs) (*Server, error) {
	e := &model.Environment{
		ServiceDiscovery: aggregate.NewController(),
		PushContext:      model.NewPushContext(),
		DomainSuffix:     args.Config.ControllerOptions.DomainSuffix,
	}
	s := &Server{
        ...
		environment:     e,
        ...
	}

// NewController creates a new Aggregate controller
func NewController() *Controller {
	return &Controller{
		registries: make([]serviceregistry.Instance, 0),
	}
}

func NewServer(args *PilotArgs) (*Server, error) {
	e := &model.Environment{
		ServiceDiscovery: aggregate.NewController(),
		PushContext:      model.NewPushContext(),
		DomainSuffix:     args.Config.ControllerOptions.DomainSuffix,
	}
	s := &Server{
        ...
		environment:     e,
        ...
	}

    ...
	if err := s.initControllers(args); err != nil {
		return nil, err
	}
}

func (s *Server) initControllers(args *PilotArgs) error {
    ...
	if err := s.initServiceControllers(args); err != nil {
		return fmt.Errorf("error initializing service controllers: %v", err)
	}
	return nil
}

func (s *Server) initServiceControllers(args *PilotArgs) error {
	serviceControllers := s.ServiceController()
	registered := make(map[serviceregistry.ProviderID]bool)
	for _, r := range args.Service.Registries {
		serviceRegistry := serviceregistry.ProviderID(r)
		if _, exists := registered[serviceRegistry]; exists {
			log.Warnf("%s registry specified multiple times.", r)
			continue
		}
		registered[serviceRegistry] = true
		log.Infof("Adding %s registry adapter", serviceRegistry)
		switch serviceRegistry {
		case serviceregistry.Kubernetes:
			if err := s.initKubeRegistry(serviceControllers, args); err != nil {
				return err
			}
		case serviceregistry.Consul:
			if err := s.initConsulRegistry(serviceControllers, args); err != nil {
				return err
			}
		case serviceregistry.Mock:
			s.initMockRegistry(serviceControllers)
		default:
			return fmt.Errorf("service registry %s is not supported", r)
		}
	}

	s.serviceEntryStore = serviceentry.NewServiceDiscovery(s.configController, s.environment.IstioConfigStore, s.EnvoyXdsServer)
	serviceControllers.AddRegistry(s.serviceEntryStore)

    ...

	// Defer running of the service controllers.
	s.addStartFunc(func(stop <-chan struct{}) error {
		go serviceControllers.Run(stop)
		return nil
	})

	return nil
}

func (s *Server) initKubeRegistry(serviceControllers *aggregate.Controller, args *PilotArgs) (err error) {
    ...
	kubeRegistry := kubecontroller.NewController(s.kubeClient, s.metadataClient, args.Config.ControllerOptions)
	s.kubeRegistry = kubeRegistry
	serviceControllers.AddRegistry(kubeRegistry)
	return
}

func (c *Controller) AddRegistry(registry serviceregistry.Instance) {
	c.storeLock.Lock()
	defer c.storeLock.Unlock()

	registries := c.registries
	registries = append(registries, registry)
	c.registries = registries
}

func NewServer(args *PilotArgs) (*Server, error) {
	e := &model.Environment{
		ServiceDiscovery: aggregate.NewController(),
		PushContext:      model.NewPushContext(),
		DomainSuffix:     args.Config.ControllerOptions.DomainSuffix,
	}

	s := &Server{
		clusterID:       getClusterID(args),
		environment:     e,
        ...
	}

    ...

	if err := s.initControllers(args); err != nil {
		return nil, err
	}

    ...
	if err := s.initRegistryEventHandlers(); err != nil {
		return nil, fmt.Errorf("error initializing handlers: %v", err)
	}
    ...

	return s, nil
}

// initRegistryEventHandlers sets up event handlers for config and service updates
func (s *Server) initRegistryEventHandlers() error {
	// Flush cached discovery responses whenever services configuration change.
	serviceHandler := func(svc *model.Service, _ model.Event) {
		pushReq := &model.PushRequest{
			Full: true,
			ConfigsUpdated: map[model.ConfigKey]struct{}{{
				Kind:      model.ServiceEntryKind,
				Name:      string(svc.Hostname),
				Namespace: svc.Attributes.Namespace,
			}: {}},
			Reason: []model.TriggerReason{model.ServiceUpdate},
		}
		s.EnvoyXdsServer.ConfigUpdate(pushReq)
	}
	if err := s.ServiceController().AppendServiceHandler(serviceHandler); err != nil {
		return fmt.Errorf("append service handler failed: %v", err)
	}

    ...

	return nil
}

// AppendServiceHandler implements a service catalog operation
func (c *Controller) AppendServiceHandler(f func(*model.Service, model.Event)) error {
	for _, r := range c.GetRegistries() {
		if err := r.AppendServiceHandler(f); err != nil {
			log.Infof("Fail to append service handler to adapter %s", r.Provider())
			return err
		}
	}
	return nil
}

	serviceHandler := func(svc *model.Service, _ model.Event) {
		pushReq := &model.PushRequest{
			Full: true,
			ConfigsUpdated: map[model.ConfigKey]struct{}{{
				Kind:      model.ServiceEntryKind,
				Name:      string(svc.Hostname),
				Namespace: svc.Attributes.Namespace,
			}: {}},
			Reason: []model.TriggerReason{model.ServiceUpdate},
		}
		s.EnvoyXdsServer.ConfigUpdate(pushReq)
	}
